7” Dual Cameras Face Recognition Terminal
Model
FS1002I-N21S-FDLH-M06
Features:
- Support real time live detection
- Support tracking of personnel movements under strong backlight conditions
- Face recognition algorithm to accurately recognize faces, face recognition time is less than 0.5s
- Built-in domestic CPU
- Using Linux operating system, better system stability
- The camera uses H.265 Main Profile encoding, compatible with NVR and other storage devices through the ONVIF/ GB28181 protocol
- Support TF card storage, pictures are stored continuously for 1 year or longer (depends on TF card capacity)
- Mean time between failures MTBF>50000 H
- Support TF card storage, pictures are stored continuously for 1 year, video is stored continuously for 7 days
- Support 10000+ face matching library and 60000 face recognition records
- Rich interface protocol, support TCP/IP, UDP, RTP, RTSP, RTCP, HTTP, DNS, DDNS, DHCP, SMTP, UPNP, MQTT protocol, Windows/Linux.
- From -30 ℃ to + 60 ℃ environment for long-term stable operation
- Outdoor IP66 waterproof and dust proof
- Built-in light sensor, automatically adjust the opening and closing of the fill light
- Rich hardware interface （I/O, WG26, WG34, RJ45）
- 7-inch IPS full-view HD display, no streaking and delay
- Support automatic gain control and automatic white balance
- 3D noise reduction and fog-passing technology makes the monitoring picture under low illumination more clear and delicate
- Support code stream and I frame interval setting
- Support video area partial blocking
- Support ROI coding
- Support setting maximum exposure time
- Support 2D noise reduction, 3D noise reduction
- Support recording schedule time period and upload mode setting
- Support video brightness, contrast, hue, saturation, gamma adjustment
- Support setting the maximum auto exposure time
- Support face intelligent exposure, face smart enhancement settings
Specifications:
| Model | FS1002I-N21S-FDLH-M06 |
| Hardware | |
| Processor | Dual Core Processor + 1G memory + 8G flash |
| Operating system | Linux Operating system |
| Storage | Support TF card storage |
| Sensor | 1/2.8″ Progressive Scan CMOS |
| Lens | 6mm |
| Performance | |
| Recognition height | 1.2~2.2 meters，angle can be adjusted |
| Recognition distance | 0.5~1.5 meters，depends on lens |
| Face angle | 30 degrees left and right, 30 degrees up and down |
| Recognition time | Less than 0.5 seconds |
| Function | Support 60000 capture library, real-time capture, support 10000 list library |
| Interface | |
| Switch inputs | 1ch switch input |
| Network interface | 1x RJ45 10M / 100M Adaptive Ethernet port |
| Wiegand interface | 1ch Wiegand interface input/output |
| USB interface | 1ch USB interface |
| Camera Data |
| Camera | Dual cameras | |
| Effective pixels | 2MP, 1920*1080 | |
| Min illumination | Color 0.01Lux @F1.2(ICR);B/W 0.001Lux @F1.2 (ICR) | |
| SNR | ≥50db(AGC OFF) | |
| WDR | 100db | |
| Video coding | H.265 Main Profile/ H.264 BP/MP/HP /MJPEG | |
| Resolution | Main stream | 50Hz: 25fps (1920×1080,1280×720) |
| 60Hz: 30fps (1920×1080,1280×720) | ||
| Sub stream | 720*576，1-25(30)fps/640*480，1-25(30)fps 320*240，1-25(30)fps | |
| Regular | ||
| Operating temperature | -30 ℃ – +60 ℃ | |
| Working humidity | 0～90% relative humidity, no condensation | |
| Powered by | DC12V/3A | |
| Power | 20W(MAX) | |
| Device size | 128(W) * 28(T) *240(L)mm | |
| Screen size | 7 inches | |
| Weight | 1.5 kg（without base plate） |
Device Size:
Interface:
| No. | Name | Quantity | Remark |
| 1 | Network | 1 | RJ45 |
| 2 | Power | 1 | DC12V IN |
| 3 | USB | 1 | USB 2.0 |
| 4 | Switch Output | 1 | Switch output interface A+/B- |
| 5 | Wiegand protocol input interface | 1 | vcc12VGNDD0D1 |
| 6 | Wiegand protocol output interface | 1 | vcc12VGNDD0D1 |
| 7 | RS485 | 1 | 485-485+ |
